Sample Carrier PCB Board Connectors
Select a connector type below to view the PCB's and details.
Contact:
Info-demoLR@tudelft.nl
0152787983
FFC10 Connector
Sample Carrier PCBs using 10-pin flat flex connectors (FFC10):
2009
| Connector:FFC10, name:Reimer, nr:09-011-1 size (LxWxT): 30.8 x 30.8 x 1.55 mm description: sample holder (on attocube in cryostat) with 2x10 pin  more info more info |
Connectoradaptor:FFC10, name:Reimer, nr:09-011-2 size(LxWxT): 8 x 5 x 0.2 mm  more info |
2013
| Connector:FFC10, name:Bavinck I, nr:13-022 size(LxWxT): 40 x 42.5 x 1.55 mm  more info |
FFC14 Connector
Sample Carrier PCBs using 14-pin flat flex connectors (FFC14):
2011
| Connector:FFC14, name:Laird, nr:11-010-2 size(LxWxT):43 x 43 x 1.55 mm
 more info |
Connector:FFC14, name:Laird, nr:11-010-3 size(LxWxT): 8 x 10.5 x 0.2 mm
 more info |
FFC35 Connector
Sample Carrier PCBs using 35-pin flat flex connectors (FFC35):
Unknow
| Connector:FFC35, name:, nr: size (LxWxT): description: sample holder ("cold finger") with 32 wire&grounding connector
 more info N/A |
2008
| Connector:FCC35, name:, nr:08-002-1 size(LxWxT): description:Flatcable connectors, connection board
 more info |
Connector:FCC35, name:, nr:08-008-1 size(LxWxT): description: Sample Boards Steele
 more info |
Connector:FCC35, name:, nr:08-008-2 size(LxWxT): description: Sample Boards Steele
 more info |
Connector:FCC35, name:, nr:08-008-3 size(LxWxT): description: Sample Boards Steele
 more info |
Connector:FCC35, name:, nr:08-008-4 size(LxWxT): description: Sample Boards Steele
 more info |
Connector:FCC35, name:, nr:08-008-5 size(LxWxT): description: Sample Boards Steele
 more info |
Connector:FCC35, name:, nr:08-008-6 size(LxWxT): description: Sample Boards Steele
 more info |
Connector:FCC35, name:, nr:08-002-2 size(LxWxT): description: Flatcable connectors, short board
 more info |
2009
| Connector:2xFFC35, name:Goosens, nr:09-002 size (LxWxT):17 x 25 x 1.55 mm description:Copper Finish: Chemisch Au/Ni Selective
 more info |
Connector:FCC35, name:Nadj-Perge, nr:09-012-3 size(LxWxT):15 x 30 x 1.55 mm  more info |
Connector:FCC35, name:, nr:08-002-1 size(LxWxT): description:Flatcable connectors, connection board
more info |
2010
| Connector:FFC35, name:Buchs, nr:10-007 size (LxWxT):26.4 x 40.8 x 1.55 mm description: Connector: PLCC 32 Way 1.27mm Pitch, Copper Finish: Chemisch Au/Ni Selective
 more info |
2011
| Connector:FFC35, name:Zuo, nr:11-007-2 size (LxWxT):35 x 32 x 1.55 mm description: Connector: PLCC 32 Way 1.27mm Pitch, Copper Finish: Chemisch Au/Ni Selective
 more info |
2013
| Connector:FFC35, name:Schneider I, nr:13-021 size (LxWxT):25 x 15 x 1.55 mm description: Copper Finish: Chemisch Au/Ni Selective
 more info |
Connector:FFC35, name:Geresdi I, nr:13-010 size (LxWxT):25 x 32.5 x 0.8 mm description:Copper Finish: Chemisch Au/Ni Selective
 more info |
FFC35-SMA
| Connector:FFC35-SMA, name:, nr: size (LxWxT):56 x 35 x ? mm description:pcb 4xrf, 32 filtered dclines + 4 RFsma + 4 biastees  more info |
Connector:FFC35-SMA, name:, nr:fb001a size (LxWxT): description:pcb's fb001a rf-readout LC  more info N/A |
Connector:FFC35-SMA, name:, nr:fb001b size (LxWxT): description:pcb's fb001b rf-readout LC  more info N/A |
2009
| Connector:FFC35-SMA, name:Esparza, nr:09-008 size (LxWxT): 35 x 56.5 x 1.55 mm description:Copper Finish: Chemisch Au/Ni Selective
 more info |
2010
| Connector:FFC35-3xSMA, name:Meerwaldt, nr:10-005 size (LxWxT): 40 x 30 x 1.55 mm description:Copper Finish: Chemisch Au/Ni Selective
 more info |
Connector:FFC35-SMA, name:Schreiber, nr:10-006 size (LxWxT): 25 x 43 x 1.55 mm description:Copper Finish: Chemisch Au/Ni Selective
 more info |
Connector:FFC35-SMA, name:Shafiei, nr:10-008-1 size (LxWxT): 25 x 43 x 1.55 mm description:Copper Finish: Chemisch Au/Ni Selective
 more info |
Connector:FFC35-SMA, name:Shafiei, nr:10-008-2 size (LxWxT): 56.5 x 35 x 1.55 mm description:Copper Finish: Chemisch Au/Ni Selective
 more info |
Connector:FFC35-SMA, name:Shafiei, nr:10-008-3 size (LxWxT): 25 x 43 x 1.55 mm description:Copper Finish: Chemisch Au/Ni Selective
 more info |
2011
| Connector:3xFFC35-2xSMA, name:Giethoorn, nr:11-009 size (LxWxT): 72 x 30 x 1.55 mm description:Copper Finish: Chemisch Au/Ni Selective
 more info |
Connector:2xFFC35-2xSMA, name:Laird, nr:11-010-1 size (LxWxT): 43 x 23 x 1.55 mm description:Copper Finish: Chemisch Au/Ni Selective
 more info |
2013
| Connector:FFC35-3xSMA, name:Shafliei IV, nr:13-006 size (LxWxT): 56.5 x 35 x 1.55 mm description:Copper Finish: Chemisch Au/Ni Selective
 more info |
Connector:FFC35-3xSMA, name:Shafliei V, nr:13-009 size (LxWxT): 57.24 x 35.1 x 1.55 mm description:Copper Finish: Chemisch Au/Ni Selective
 more info |
2014
| Connector:FCC35-SMA, name:Kawakami, nr:14-021 size(LxWxT):61 x 35 x 1.55 mm  more info |
2015
| Connector:FFC35-SMA, name:, nr:15-011-1 size (LxWxT):35 x 55 x ? mm
 more info more info |
FFC35-FFC20
2015
| Connector:FFC35-FFC20, name:Scarlino, nr:15-011-2 size (LxWxT):18 x 25 x ? mm  more info more info |
Connector:FFC35-FFC20, name:Zhang, nr:15-014-2 size (LxWxT):32 x 24 x ? mm  more info more info |
FFC35-2.54mm Harwin Header
2009
| Connector:FCC35, name:Nadj-Perge, nr:09-012-1 size(LxWxT):52 x 25 x 1.55 mm  more info |
Connector:FCC35, name:Nadj-Perge, nr:09-012-2 size(LxWxT):45 x 61 x 1.55 mm  more info |
FFC35-FFC10
2018
| Connector:FFC35-FFC10, name:Pascal Gehring, nr:18-015 size (LxWxT): 49 x 24 x ? mm  more info |
FFC50 Connector
QuTech Sample Carrier PCBs with FFC50 Connector
2014
|
Connector:FCC50, name:Mensingh, nr:14-020-1
size(LxWxT):31 x 32.5 x 0.8 mm
more info |
Connector:FCC50, name:Mensingh, nr:14-020-2
size(LxWxT):31 x 17 x 0.2 mm
more info |
2016
|
Connector:FFC50-SMP, name:Udit, nr:16-018
size (LxWxT):64 x 35 x ? mm Description:
more info |
2018
|
Connector:FFC50, name:Andrea Corna, nr:18-008
size (LxWxT):65 x 35 x ? mm Description: PCB DRAM, Sample board
more info |
Connector:FFC50, name:Daniël, nr:18-014
size (LxWxT):74.5 x 33 x ? mm / 110 x 33 x ? mm Sample Hole: 10 x 10 mm Description: Sample board/interface
more info |
|
Connector:FFC50, name:Stephan Philips, nr:18-016
size (LxWxT):56 x 47 x ? mm Description: Sample board
more info |
Connector:FFC50, name:Atilla, nr:18-017
size (LxWxT):35.5 x 30 x ? mm Sample hole: 10 x 10 mm Description: Sample board
more info |
|
Connector:FFC50, name:Anne-marije, nr:18-018
size (LxWxT):56 x 47 x ? mm Description: Sample board
more info |
2019
|
Connector:FFC50, name:AttoCube Alberto, nr:19-013
size (LxWxT):34 x 34 x ? mm Description: Sampleboard
more info |
Connector:FFC50, name:AttoCube Brian Luca, nr:19-019
size (LxWxT):33.8 x 33.8 x ? mm Description: Sampleboard
more info |
2020
|
Connector:FCC50, name:, nr:20-013
size (LxWxT):size (LxWxT): 35.5 x 30 x 3 mm Description: Redesign 14-020 V2, Sampleboard, Boardthickness = 1.0mm
more info |
Connector:FFC50, name:, nr:20-014
size (LxWxT): 80 x 45 x ? 0.88 mm Description: Redesign 17-022, Sampleboard, Rogers material
more info |
|
Connector:, name:, nr:20-016
size (LxWxT): 51.55 x 31.2 x 0.7 mm Description: Redesign 13-011v, Sampleboard, Rogers material, Finish = Silver immersion
more info |
2021
|
Connector:FFC50, name:Andersen, nr:21-010
size (LxWxT): 100 x 50 x ? mm sample hole: 9.2 x 9.2mm Description: RF Sample board
more info |
2022
|
Connector:FFC50, name:Christian Prosko, nr:22-002
size (LxWxT): 52 x 35 x 1.5 mm Dielectric: Megtron 6K sample area: 11 x 11mm
more info |
Connector:FFC50, name:D. van Driel, nr:22-032
size (LxWxT): 51,6 x 35 x 1,2 mm sample hole: 15 x 10mm Description:
more info N/A |
2023
|
Connector: FFC50 and SMP, name: Nodar Samkharadze V2, nr: 23-001
Size (LxWxT): 56 x 47 x 1.5 mm
more info |
Connector: FFC50(DC)2x24 Ardent(RF In) 1x SMP(RF Read-out), name: 48 Channel Sample Board Nico Hendrickx, nr: 23-025
Size (LxWxT): 52 x 110 x 1.8 mm
more info |
2024
|
Connector: FFC50 and SMP, name: Nodar Fabien, nr: 24-001
Size (LxWxT): 70 x 47 x 1.25 mm
more info |
Connector: FFC50 and SMP, name: C. Andersen V4, nr: 24-009
Size (LxWxT): 73 x 40 x 1.72 mm
more info |
Connector: FFC50 and SMP, name: Sergey Aminotov, nr: 24-027
Size (LxWxT): 56 x 47 x 1.25 mm
more info |
Connector: FFC50 and SMP, name: M. Zwanenburg, nr: 24-028
Size (LxWxT): 100 x 50 x 1.72 mm
more info |
2025
|
Connector: FFC50 and SMP, name: Praveen V, nr: 25-004
Size (LxWxT): 50 x 50 x 1.55 mm
more info |
Miscellaneous Connectors
This section includes less common or specialized connector types used in various test setups.
Pads
| Connector:?, name:, nr:
size (LxWxT):14.3 x 12.5 mm x 0.25mm description:QDCAR2 dc-lines + rf-gate
more info |
Connector:, name:, nr:
size (LxWxT):14.3 x 12.5 mm x 0.25mm description:QDCAR2b dc-lines + bias-tee on rf-gate
more info N/A |
| Connector:?, name:, nr:
size (LxWxT): ? x ? mm x 0.25mm description:QDCAR3 dc-lines + rf-gate
more info N/A |
Connector:, name:, nr:
size (LxWxT):? x ? mm x 0.25mm description:QDCAR4b dc-lines + 2 rf-Gates
more info N/A |
| Connector:, name:, nr:
size (LxWxT): ? x ? x 1.6/0.8 mm description:CARHAN1 12 pulse line connections
more info N/A |
Connector:Pads, name:, nr:
size (LxWxT): ? x ? x 1.6 mm description:CARAFM1 afm-sample holder. cutout for sample
more info |
| Connector:Pads, name:, nr:
size (LxWxT): ? x ? x 1.6 mm description:CARUMB1 sample holder, backgate-electrode
more info N/A |
Connector:Pads, name:, nr:
size (LxWxT): ? x ? x 0.8 mm description:CARTEM3 holder for sample TEM-microscope
more info N/A |
| Connector:Pads, name:Mattoni, nr:14-004
size (LxWxT): 11.75 x 20 x 1.55 mm description:Copper Finish:Chemisch Ni/Au Selectief
more info N/A |
SMA
Return to Top| Connector:SMA/Pins, name:, nr:
size (LxWxT): description: sample holder optics carluc1, dc+2rf (SMA)
more info N/A |
Connector:SMA, name:, nr:
size (LxWxT):? x ? x 1.6 mm description:CARAD1 for microwave resonator. partial cutout for chip
more info |
| Connector:SMA, name:, nr:
size (DxT):20 x 1.6 mm description: PDETCAR1 single photon det. carrier SMA
more info N/A |
Connector:SMA, name:, nr:
size (DxT):30 x 1.6 mm description:PDETCAR3 single photon 2det. carrier SMA
more info N/A |
| Connector:SMA, name:, nr:
size (LxWxT):23.7 x 22.4 x 1.6 mm description: RABCAR2 SMA connectors, rf-resonance in/out/ +microwave. cutout for sample
more info more info |
Connector:SMA, name:, nr:
size (LxWxT):23.7 x 22.4 x 1.6 mm description:RABCAR3 SMA connectors, rf-resonance in/out/ +microwave
more info N/A |
| Connector:SMA-Pins, name:v Dam, nr:16-012
size (LxWxT):45 x 35 x ? mm Sample Hole: 2.2 x 2.2 mm
more info |
Connector:SMA, name:Cramer, nr:14-001
size (LxWxT):45 x 35 x 1.55 description: 4x SMA Straight Angle, Copper Finish: Chemisch Ni/Au Selectief
more info |
| Connector:4xSMA, name:, nr:14-019-2
size (LxWxT):40 x 40 x 1.55 mm description: Copper Finish: Chemisch Ni/Au Selectief
more info |
Connector:4xSMA, name:Bosman, nr:12-005
size (LxWxT):21 x 34.5 x 1.55 mm description: Copper Finish: Chemisch Ni/Au Selectief
more info |
| Connector:SMA, name:S Steele, nr:12-007-1
size (LxWxT):15 x 24 x 1.55 mm description: Copper Finish: Chemisch Ni/Au Selectief
more info |
Connector:SMA, name:S Steele, nr:12-007-2
size (LxWxT):15 x 44 x 1.55 mm description: Copper Finish: Chemisch Ni/Au Selectief
more info |
| Connector:SMA, name:S Steele, nr:12-007-3
size (LxWxT):15 x 79 x 1.55 mm description: Copper Finish: Chemisch Ni/Au Selectief
more info |
Connector:SMA-2x 4 pins 2 rows Harwin 2.54mm Header, name:Soini, nr:12-008
size (LxWxT):39 x 28 x 1.55 mm description: Copper Finish: Chemisch Ni/Au Selectief
more info |
| Connector:SMA, name:Hans Beukers, nr:22-004
size (LxWxT):32 x 22.75 x 0.50 mm Dielectric: Isola-Tera
more info |
Connector:SMA, name:, nr:22-006
size (LxWxT):? x ? x ? mm description: Test Board Sample Impedance Matching
more info |
Connector: SMA, description: Redesign 22-004, name: Christopher Waas, nr: 23-013
more info |
Connector: SMA, description: Redesign 23-013, name: Christopher Waas, nr: 23-020
more info |
SMC
Return to Top| Connector:SMC/Pins, name:, nr:
size (LxWxT): description: sample holder optics hannes, dc+4rf (SMC)
more info N/A |
SMP
Return to Top| Connector:SMP, name:, nr:
size (LxWxT): description: Microwave sample carrier (Pieter) ceramic substrate TMM10, smp-connectors
more info N/A |
Connector:SMP, name:, nr:
size (LxWxT): description: Microwave sample carrier (Patrice) ceramic substrate TMM10
more info |
| Connector:SMP, name:, nr:
size (LxWxT):? x ? x 3.2 mm description:CARDIAM1 holder square glass diamant NVsample , roomtemperature. cutout for objective, transmission lines to sample
more info |
Connector:SMP, name:Zheng, nr:16-004
size (LxWxT):51 x 40 x ? mm
more info |
| Connector:FFC51/SMP, name:Dehollain, nr:16-006
size (LxWxT):52 x 35 x ? mm
more info |
Connector:SMP-FFC40, name:Homulle, nr:16-020
size (LxWxT):55 x 30 x ? mm
more info |
| Connector:smp, name:?, nr:19-016
size (LxWxT):35 x 11.5 x ? mm Sample Hole: 10 x 5 mm
more info |
Connector:smp, name:Brecht Simon, nr:19-022
size (LxWxT):24 x 15 x ? mm
more info |
| Connector:SMP, name:, nr:18-006
size (LxWxT):? Description:Sampleboard Thierschmann V2
more info |
Connector:SMP, name:Matthew, nr:20-018
size (LxWxT):49 x 36.5 x 0.5 mm
more info |
| Connector:SMP, name:Jasper Franse, nr:21-008
size (LxWxT):48 x 48 x 1.55 + SMP mm sample hole size: 7 x 7mm
more info |
Connector:SMP, name:Gary Jacob, nr:21-011
size (LxWxT):48 x 48 x ? mm sample hole: 10.1 x 10.1mm
more info |
| Connector:SMP, name:Jean-Paul, nr:21-017
size (LxWxT):40 x 20 x ? mm
more info |
Connector:SMP, name:Kroll, nr:15-003-2
size (LxWxT):43.3 x 35.3 x ? mm
more info |
| Connector:SMP, name:Mykhaylov, nr:15-012
size (LxWxT):49 x 32 x ? mm
more info |
Connector:SMP/NanoD50, name:Shafiei VI, nr:14-005
size (LxWxT):52 x 35 x 1.55 mm description: Copper Finish: Chemisch Ni/Au Selectief
more info |
| Connector:8x SMP, name:Samkharadze, nr:14-013-1
size (LxWxT):30 x 30 x 0.5 mm description: Copper Finish: Chemisch Ag Selectief
more info |
Connector:8x SMP-2xNanoD50, name:Samkharadze, nr:14-013-2
size (LxWxT):50 x 40 x 1.55 mm description: Copper Finish: Chemisch Ni/Au Selectief
more info |
| Connector:10xSMP-2xNanoD50, name:Bart, nr:14-022
size (LxWxT):52 x 35 x 0.8 mm description: Copper Finish: Chemisch Ni/Au Selectief
more info |
Connector:6xSMP-2xNanoD50, name:Cassidy I, nr:13-011
size (LxWxT):51 x 37 x 1.55 mm description: Copper Finish: Chemisch Ni/Au Selectief
more info |
| Connector:14xSMP, name:Martijn Zwanenburg, nr:22-033-1
size (LxWxT):100 x 50 x 0.8 mm description:
more info |
Connector:30xSMP, nr:22-033-2
size (LxWxT): 100 x 50 x 0.8 mm sample area: 9,2 x 9,2 mm
more info |
| Connector:SMP, name:Laurens Feije, nr:22-031
size (LxWxT):32 x 22.75 x 0.50 mm
more info |
Connector: 16,20,4,4xSMP , name: Niccolo Jana, nr:23-005 Size (LxWxT): 23-005-1: 28 x 20.5 x 1.5 mm 23-005-2: 55 x 51 x 1.5 mm 23-005-3: 55 x 52 x 1.5 mm 23-005-4: 27 x 20.5 x 1.5 mm
more info |
Connector: SMP, description: Cavity Sample Board, name: Yanik Herrmann, nr: 23-012
more info |
|
|
Connector: SMP, name: Xinxin, nr: 25-003
Size (LxWxT): 19.75 x 26 x 1 mm
more info |
|
|
Connector: SMP, name: Matteo, nr: 25-006-1/2
Size 25-006-1 (LxWxT): 20 x 40 x 1.06 mm Size 25-006-2 (LxWxT): 20 x 21 x 1.06 mm
more info |
SMB
Return to Top| Connector:5xSMB, name:Shakeri, nr:12-006
size (LxWxT):40 x 40 x 1.55 mm description: Copper Finish: Ni/Au Selectief
more info |
Pins/Header
Return to Top| Connector:Pins, name:Davidovikj, nr:16-001
size (LxWxT):38 x 25 x ? mm
more info |
Connector:SMA-Pins, name:v Dam, nr:16-012
size (LxWxT):45 x 35 x ? mm Sample Hole: 2.2 x 2.2 mm
more info |
| Connector:SMA/Pins, name:, nr:
size (LxWxT): description: sample holder optics carluc1, dc+2rf (SMA)
more info N/A |
Connector:SMC/Pins, name:, nr:
size (LxWxT): description: sample holder optics hannes, dc+4rf (SMC)
more info N/A |
| Connector:FFC40/Header, name:Zhang, nr:15-014-1
size (LxWxT):30 x 20 x ? mm
more info |
Connector:FFC10/Header, name:Mattoni, nr:14-004-2
size (LxWxT):24 x 28 x 1.55 mm description: Copper Finish:Chemisch Ni/Au Selectief
more info |
| Connector:Pins, name:Carel Heerkens, nr:13-012
size (LxWxT):?
more info N/A |
Connector:3x 2x4 pins 2.54 mm header, name:Bosman, nr:12-005-2
size (LxWxT):50 x 28 x 1.55 mm
more info |
| Connector:Pins, name:Esparza, nr:09-010
size (LxWxT):?
more info |
NanoD
Return to Top| Connector:NanoD50, name:Toivo, nr:16-013
size (LxWxT):80 x 50 x ? mm
more info |
Connector:NanoD50, name:Pei, nr:14-003-1
size (LxWxT):43 x 41.5 x 0.8 mm description:2x Nano-D 50-pins Right Angle 1x SMP Straight Angle, Copper Finish:Chemisch Ni/Au Selectief
more info |
| Connector:NanoD50, name:Pei, nr:14-003-2
size (LxWxT):43 x 39 x 0.8 mm description: 2x Nano-D 50-pins Right Angle, Copper Finish:Chemisch Ni/Au Selectief
more info |
Connector:SMP/NanoD50, name:Shafiei VI, nr:14-005
size (LxWxT):52 x 35 x 1.55 mm description: Copper Finish: Chemisch Ni/Au Selectief
more info |
| Connector:2x NanoD50, name:Pribiag I, nr:14-006
size (LxWxT):43 x 39 x 1.55 mm description: Copper Finish: Chemisch Ni/Au Selectief
more info |
Connector:8x SMP-2xNanoD50, name:Samkharadze, nr:14-013-2
size (LxWxT):50 x 40 x 1.55 mm description: Copper Finish: Chemisch Ni/Au Selectief
more info |
| Connector:2x NanoD50, name:Beukman, nr:14-019
size (LxWxT):44 x 25 x 1.55 mm description: Copper Finish: Chemisch Ni/Au Selectief
more info |
Connector:2x NanoD50, name:vWoerkom I, nr:13-028
size (LxWxT):53 x 49 x 0.8 mm description: Copper Finish: Chemisch Ni/Au Selectief
more info |
Sub-D
Return to Top| Connector:2xSub-D25, name:Cassidy II, nr:13-023-1
size (LxWxT):35.5 x 71 x 1.55 mm description: Copper Finish: Chemisch Ni/Au Selectief
more info |
Connector:2xSub-D25, name:Cassidy II, nr:13-023-2
size (LxWxT):35.5 x 71 x 1.55 mm description: Copper Finish: Chemisch Ni/Au Selectief
more info |
| Connector:2xSub-D25, name:Cassidy II, nr:13-023-3
size (LxWxT):35.5 x 71 x 1.55 mm description: Copper Finish: Chemisch Ni/Au Selectief
more info |
|
FFC40
Return to Top| Connector:SMP-FFC40, name:Homulle, nr:16-020
size (LxWxT):55 x 30 x ? mm
more info |
Connector:FFC40/Header, name:Zhang, nr:15-014-1
size (LxWxT):30 x 20 x ? mm
more info |
SMT
Return to Top| Connector:smt, name:Mattias Matthiesen, nr:19-023
size (LxWxT):23 x 9 x ? mm
more info |
Harwinn
Return to Top| Connector:Harwinn, name:Buscema I, nr:14-016 size (LxWxT):23.5 x 23. x 1.55 mm description: Connector:4x 7-pins 2.54mm Harwinn Connector, Copper Finish: Chemisch Ni/Au Selectief  more info |
Connector:SMA-2x 4 pins 2 rows Harwin 2.54mm Header, name:Soini, nr:12-008 size (LxWxT):39 x 28 x 1.55 mm description: Copper Finish: Chemisch Ni/Au Selectief
more info |
| Connector:Harwinn, name:Zuo, nr:11-007-1 size (LxWxT):32 x 32 x 1.55 mm description: Connector:2 x Harwin 2.54mm Header 11-pins, Copper Finish: Chemisch Ni/Au Selectief
 more info |
Connector:2xHarwinn-4xSMA, name:Zuo, nr:11-008 size (LxWxT):35 x 45 x 1.55 mm description: Connector:2 x Harwin 2.54mm Header 8-pins, Copper Finish: Chemisch Ni/Au Selectief  more info |
MCX
Return to Top| Connector:FCC35, name:, nr:08-008-7
size(LxWxT): description: Sample Boards Steele
more info |
Spring-load
Return to Top| Connector: Spring-load, name:, nr:22-019
size (DxT): 31 x 1.06mm Dielectric: Rogers 4350 sample area: 10 x 10mm Finish: soft gold without nickel
more info |
Connector: Spring-load, description: Redesign, name: Gary Steele, nr: 23-011
size (DxT): 30 x 1.06mm Dielectric: Rogers 4350 sample area: 10 x 10mm Finish: soft gold without nickel
more info |
Unknown
Return to Top| Connector:, name:Tierschmann, nr:16-023
size (LxWxT):
more info N/A |
MicroD Connector
DEMO/QuTech -sample carrier pcboards with MicroD Connector
